Lowrance Outboard Pilot Hydraulic Steered With PUMP1

Lowrance Outboard Pilot Hydraulic Pack

Available for HDS Gen2 Keypad units only (*available Q2 for HDS Gen2 Touch and HDS Gen3)

Model: 000-11748-001
UPC: 9420024134313

• Steer your outboard motor to a heading, waypoint, route or cursor, with control from your HDS Gen2 display.
• New Lowrance SmartSteer™ interface provides control of both your hydraulic-steer outboard motor, as well as the MotorGuide Xi5 Pinpoint electric-steer trolling motor.
• ?One-touch? route creation from saved trails.
• Repeat your path with automatic turn patterns.
• Recommended for single-outboard setups, on boats that are 30 feet and less, in length.
• VRF (Virtual Rudder Feedback) — simplifies pilot installation — eliminating the need for a rudder position sensor.
• Easy setup — straightforward guide steps you through first-time install.
• Easy-to-install, plug-and-socket connection — with no complex terminal wiring
• Supported by Lowrance Advantage Service program

Autopilot pack for Lowrance High Definition System (HDS) displays, providing automatic steering for hydraulic-steer outboard motors. An extra pair of hands when you need it, the Outboard Pilot, featuring Lowrance SmartSteer™ control from your HDS Gen2, will steer to a heading, waypoint or route.

Everything you need in one box to fit an autopilot to your hydraulic-steer outboard motor, the Outboard Pilot lets you focus on fishing activity while keeping the boat on course (NOTE: Mercury Verado motors require the Verado Fitting Kit).When connected to an HDS Gen2, the Outboard Pilot can steer to a waypoint or along a route, select a turn pattern or simply hold a constant heading. The Lowrance SmartSteer™ user interface allows you to easily switch between electric-steer, trolling-motor control and outboard motor control directly from your HDS display. And, with your HDS display, you can easily convert trails to routes — so you can retrace a previous track and get your boat back to the dock from your fishing area.

The Lowrance Outboard Pilot is recommended for single outboard set-ups, on boats that are 30 feet and less, in length.

Specifications

Water rating	IPx5
NMEA input	Micro-C
Drive power ratings	NAC-1 drive output: 12V, Max 16 Amps (instantaneous)
Input Voltage	12v

What’s in the Box:

• NAC-1 Autopilot Computer 000-11769-001 – The brains behind your Lowrance Outboard Pilot system. It contains the steering computer and electronics for the drive unit motor
• PUMP-1 Hydraulic Pump 000-11771-001 – 0.8L reversible hydraulic pump, compatible with Seastar manual helm pumps up to 14ci.
• Point-1AP Heading and GPS Sensor – Provides extremely accurate and rapid boat position update, along with heading for accurate boat direction at any speed
• Hydraulic Fitting Kit – Everything you need to connect with your existing hydraulic system — including t-connectors, hoses and oil. NOTE: Mercury Verado motors require the Verado Fitting Kit
• Auto/Standby Button – Mounts anywhere on dash and changes Autopilot from STBY to AUTO mode with one press.
